L2RR-L3BLM - 22/25 mm Pilot Lights
* Image may differL2RR-L3BLM
- Protection structure : IP52
- Letter marking : None(no printing)
- Head type : Flat round(extended)
- Color : Blue
- LED block type : Modular type
Data sheet Print
| LED block_Power supply | 110-220VAC~ 50/60Hz |
|---|---|
| LED block_Current consumption | Max. 20mA |
| Protection structure | IP52 |
| Weight_Mounting hole_Ø22/25 | Approx. 15.5g |
| Weight_Housing | Approx. 7g |
| Weight_LED block_AC voltage type | Approx. 12g |
| Letter marking | None(no printing) |
| Head type | Flat round(extended) |
| Color | Blue |
| LED block type | Modular type |
| Environment_Ambient temperature | -15 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
※Environment resistance is rated no freezing or condensation.
※The light unit and LED blocks are sold separately.
※The LED color is the same as the control unit.
